July 2026 — rgbdns 0.3.3

The first rgbdns release established the larger idea: rebuild the djbdns program family in memory-safe Rust without losing the small-program design, the tinydns data format, or the ability to understand the entire authoritative serving path. The newest release turns that implementation into something an operator can deploy and keep running.

rgbdns 0.3.3 ships installable Debian and openSUSE packages, systemd services for primary and secondary authority, atomic file-drop workflows for zone data, multi-zone AXFR synchronization, and query logging compatible with both the system journal and multilog. It also carries a working implementation of ANAME address flattening that preserves the ANAME source record between upgraded rgbdns authorities during AXFR.

That last part is now also a standards proposal. The complete design has been submitted as the individual Internet-Draft Address-specific DNS Aliases (ANAME) and Zone Transfer. It is an active proposal for discussion, not an approved RFC or an IETF endorsement.

From a package to an operating nameserver

The Debian package is intended for a Debian or Ubuntu primary. Download the current .deb artifact, then install the local file with an explicit path:

sudo apt install ./rgbdns_0.3.3_amd64.deb

The openSUSE package provides the same binaries, service account, configuration layout, and role tooling:

sudo zypper install ./rgbdns-0.3.3-1.x86_64.rpm

Both packages deliberately install an inert service. Installation creates the rgbdns account and systemd units, but it does not guess whether the machine is a primary, a secondary, or neither. The role is selected once with rgbdns-setup.

For a primary at a.ns.cron.sh, the editable source can arrive as rgbdns.data in the administrator's home directory:

sudo rgbdns-setup primary \
  --data-drop /home/bitnami/rgbdns.data \
  --data-drop-owner bitnami \
  --listen-ip 0.0.0.0 \
  --allow-nets 172.31.0.125/32

The path unit watches the drop location. A complete file is validated, compiled into CDB, installed atomically, and activated without exposing a partially written database. Publishing another zone is consequently a source control and file-transfer operation, not an interactive edit on the server:

scp rgbdns.data.new primary.example:rgbdns.data.new
ssh primary.example 'mv rgbdns.data.new rgbdns.data'

For the openSUSE secondary at b.ns.cron.sh, the corresponding one-time setup names the primary's private VPC address and a drop location for the desired zone list:

sudo rgbdns-setup secondary \
  --zones-drop /home/ec2-user/rgbdns.zones \
  --zones-drop-owner ec2-user \
  --primary 172.31.60.189 \
  --listen-ip 0.0.0.0

The operator publishes one zone name per line:

fieldnotes.es
aname-axfr.test

As on the primary, upload to a temporary name and rename only after the copy finishes:

scp rgbdns.zones.new secondary.example:rgbdns.zones.new
ssh secondary.example 'mv rgbdns.zones.new rgbdns.zones'

The secondary imports the list, transfers each zone, validates the result, rebuilds its combined serving database, and keeps last-known-good data for a zone whose refresh fails. One broken zone therefore does not make healthy zones disappear.

Package upgrades preserve operator-owned configuration. Debian uses conffile semantics; RPM uses %config(noreplace). Since 0.3.3, an upgrade also restores the configured authority and role-specific path or timer units, so installing a newer package does not leave a previously running nameserver stopped.

ANAME is an alias that can live at the apex

A CNAME cannot normally coexist with the SOA, NS, and other records required at a zone apex. Hosting platforms nevertheless want customers to point an apex such as fieldnotes.es at a managed target whose addresses can change. Providers solve this today under names such as CNAME flattening, ALIAS, or ANAME.

rgbdns expresses the source intent directly in tinydns data syntax:

Zfieldnotes.es:a.ns.cron.sh:hostmaster.fieldnotes.es:2026073103:16384:2048:1048576:2560:3600
&fieldnotes.es::a.ns.cron.sh:3600
&fieldnotes.es::b.ns.cron.sh:3600
Afieldnotes.es:publication.ghost.io:300

The uppercase A is an rgbdns ANAME directive: its owner is fieldnotes.es, its target is publication.ghost.io, and 300 seconds is the TTL ceiling. A normal resolver never needs to understand a private record. When it asks for A or AAAA, each authoritative rgbdns server resolves the target and returns ordinary address records at the ANAME owner. SOA, NS, MX, TXT, and other apex data continue to coexist normally.

The subtle operational problem is transfer. Copying only today's synthesized addresses to a secondary loses the target relationship and makes the primary's temporary cache contents look like zone source. Copying an unknown private type without negotiation risks collision with another implementation's private encoding.

rgbdns therefore negotiates its experimental transfer extension explicitly. An upgraded secondary sends the RGA1 capability in EDNS option 65001. An upgraded primary may then carry the ANAME source through private-use TYPE65401, whose RDATA begins with RGA1 and whose TTL carries the configured ceiling. The secondary validates that envelope, reconstructs the uppercase A directive, and resolves the target independently. Ordinary AXFR clients receive an ordinary transfer without the private metadata.

The deployed values are experimental. The Internet-Draft requests assigned ANAME and EDNS values as TBD1 and TBD2; it does not pretend that 65401 and 65001 are permanent allocations.

Verify the system at its boundaries

On either authority, ordinary clients should see an authoritative address answer, not the transfer representation:

dig @127.0.0.1 fieldnotes.es A +norecurse
dig @127.0.0.1 fieldnotes.es SOA +norecurse

On the secondary, the retained source proves that ANAME intent survived the transfer:

sudo grep '^Afieldnotes\.es' \
  /var/lib/rgbdns/tinydns/secondary-zones/fieldnotes.es.data

The primary-to-secondary AXFR check belongs on the authorized VPC path, not on an arbitrary workstation outside AWS:

dig @172.31.60.189 fieldnotes.es AXFR

Do not widen the AXFR allow-list merely to make a public test convenient. The public checks are ordinary UDP and TCP DNS queries to a.ns.cron.sh and b.ns.cron.sh; the transfer check runs from an authorized secondary address.

The result is a deliberately small operating model: one editable data file on the primary, one declarative zone list on each secondary, atomic activation, and independent authorities that can preserve and execute the same ANAME intent.

Read the implementation and the proposal

The Internet-Draft is reproduced in full as Appendix C of the book so that the protocol argument, wire format, transfer rules, security considerations, and implementation experience travel with the operational account.
